iCraft Z890 VERTEX

CPU: LGA1851 socket for Core™ Ultra, Pentium® Gold, and Celeron® processors
Form Factor: ATX, 305mm x 245mm.
Chipset: Intel® Z890.
Memory: Dual-channel DDR5, up to 128GB, 9000 MHz (OC), Intel® XMP support.
PCIe Slots: 1 x PCIe 5.0 X16 (supports X16, X8+X8 split), 1 x PCIe 5.0 X8, 1 x PCIe 4.0 X4.
Storage: 4 x M.2 slots (PCIe 5.0/4.0), 4 x SATA 6Gb/s, 2 x SFF-8654 4i interfaces.
Networking: 5Gb Ethernet, Wi-Fi 7, Bluetooth® 5.4.
USB Ports:
- Front: 1 x USB 20G Type-C®, 1 x USB 5G (supports 2 more), USB 2.0.
- Rear: 2 x USB 40G Type-C®, 9 x USB 10G Type-A.
Audio: Realtek ALC1220 codec.
Features: Maxsun Sync RGB, BIOS Flash, onboard power/reset/RGB buttons, Resizable Bar support.
OS: Windows® 11/10 (64-bit).

你也许也喜欢

Overview

Specification

Support

Memory
2 x DIMM DDR5 slots, supporting up to 128GB
Dual-channel architecture
Supports XMP profiles at frequencies: 5600/5800/6000/7600 (OC), 8000 (OC)/8200 (OC)/8400 (OC)/8600 (OC)/9000 (OC)/9200 (OC) MHz

Expansion Slots
1 x PCIe 5.0 x16 slot (split-capable to X8+X8/X8+X4+X4)
1 x PCIe 5.0 x16 slot (supports PCIe 5.0 x8 or PCIe 5.0 x4+x4 with lane split)
1 x PCIe 4.0 x16 slot (operates at PCIe 4.0 x4)

Network
Realtek RTL8126 Ethernet chip
Intel® BE200 Wi-Fi card, supporting Wi-Fi 7 and Bluetooth 5.4

Storage
1 x M.2 slot, PCIe 5.0 x4/x2, supports 2242/2280/22110 sizes
3 x M.2 slots, PCIe 4.0 x4/x2, supports 2242/2280/22110 sizes
4 x SATA 6Gb/s ports
2 x SFF-8654 4i ports, supporting PCIe 4.0 x4/x2 or SATA (4 x SATA 6Gb/s)

USB Ports
Onboard:
1 x USB 20G Type-C® (front)
1 x USB 5G 19Pin (supports 2 additional USB 5G ports)
1 x USB 2.0 9Pin (supports 2 additional USB 2.0 ports)
1 x USB 2.0 4Pin (supports 1 additional USB 2.0 port)
