MS Intel Arc Pro B60 Dual 48G Fanless

• Model
• MAXSUN Intel Arc Pro B60 Dual 48G Fanless

• GPU Configuration
• Dual Intel® Arc™ Pro B60 GPUs

• Compute Units (Per GPU)
• 20 Xe-cores
  20 Ray Tracing Units
  160 Intel® Xe Matrix Extensions (Intel® XMX) Engines
  160 Xe Vector Engines

• Graphics Clock
• 2400MHz per GPU

• AI Performance
• 197 TOPS (INT8) per GPU

• Core Voltage
• 1.05V-1.36V per GPU

• Power Design (Per GPU)
• 6-phase VCCGT + 2-phase VCCDR + 2-phase VCCSA

• Cooling
• Fanless vapor-chamber heat dissipation design

• Graphics Memory
• 48GB GDDR6 total (24GB per GPU)
  192-bit memory interface per GPU
  456GB/s memory bandwidth per GPU
  19Gbps memory speed

• PCI Express
• PCIe 5.0 x8 per GPU

• Video Codec
• Dual Multi-Format Codec Engines
  AV1 hardware encode/decode
  H.265 (HEVC) hardware encode/decode
  H.264 hardware encode/decode
  VP9 bitstream and decoding
  HAVC-H decode

• Supported Technologies
• DirectX 12 Ultimate
  OpenGL 4.6
  XeSS-SR
  XeSS-FG
  XeSS-LL
  oneAPI
  OpenVINO

• Display Outputs (Per GPU)
• 1 × DisplayPort 2.1 UHBR20 - up to 7680 × 4320 @60Hz or 3840 × 2160 @240Hz
  1 × HDMI™ 2.1a - up to 7680 × 4320 @60Hz or 3840 × 2160 @240Hz

• Dimensions
• 302 × 110 × 40mm (L × W × H)

• Total Board Power
• 400W

• Power Connector
• 1 × 12V-2x6
