MS-T24

• Model
• MS-T24

• Product Category
• All-in-One PC

• Processor Support
• Intel 10th–15th Gen processors
  Intel N95 / N100 / N150
  Intel Core i5-12450H / i5-12600HX / i5-13420H / i7-13620H

• Chipset
• Intel H470 / H510 / H610 / H810 or Intel SoC

• Memory
• SO-DIMM DDR4 or SO-DIMM DDR5

• Storage
• 1 × M.2 2280 SATA / NVMe
  1 × 2.5-inch SATA SSD or HDD

• Graphics
• Intel HD Graphics

• Wireless / Bluetooth
• 1 × M.2 Key-E 2230; supports 802.11 b/g/n/ac and Bluetooth

• Network
• Gigabit LAN

• Speakers
• Built-in 2.0 speakers

• Camera / Microphone
• Built-in 2.0 MP or 5.0 MP camera with microphone (optional)

• Stand
• Aluminum-alloy fixed-height or height-adjustable stand

• Color
• Black / White / Gray

• Display
• 23.8-inch frameless flat IPS-level panel

• Resolution / Viewing Angle
• 1920 × 1080 / 178°

• Brightness
• 250 cd/m²

• Refresh Rate
• 60 Hz or 100 Hz

• Response Time
• 14 ms

• Color Gamut
• 99% sRGB

• I/O Ports
• 1 × HDMI
  1 × COM/VGA
  1 × RJ45
  4 × USB 3.0 + 2 × USB 2.0
  1 × DC-in (12 V or 19 V)
  1 × 3.5 mm line-out
  1 × 3.5 mm microphone input
  1 × power button
  Optional: USB 2.0 Type-C and SD card slot

• Power Input
• 48 W / 90 W / 120 W

• Dimensions
• 540 × 54 × 432 mm (L × W × H)

• Package Dimensions
• 618 × 208 × 458 mm (L × W × H)

• Net / Gross Weight
• 5.8 kg / 7.3 kg
